16 Channel, up to 8 Terabyte Black Triple Hybrid TVI/Analog/IP


  • HD-TVI H.264 DVR, Dual-stream Video Compression
  • Supports HD-TVI, IP, Analog Cameras
  • Full Channel 1080P@15fps, 720P@30fps Recording
  • HDMI and VGA output up to 1920×1080P Resolution
  • Long Transmission Distance Over 1000ft Coax Cable
  • Supports up to 16CH Simultaneous Playback
Recorder Series Others
Recorder Channel 16-Channel
Recorder Case 1U Case
Recorder Technology TVI DVR
Featured Product No
Specifications
Video / Audio input
Video compression H.264
HD-TVI video input 16ch
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adapive
IP input 2ch(1080p@30fps)
Audio compression G.711A
Audio input 1-ch, RCA(2.0 Vp-p, 1 kΩ)
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video / Audio output
HDMI / VGA output 1920 x 1080,1280 x 1024, 1280 x 720, 1024 x 768/60 Hz
CVBS output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution Main stream: 1080P(non-real-time) / 720P / WD1 / 4CIF
Sub-stream: CIF / QCIF
Frame rate Main stream: 1fps ~ Real time frame rate
Sub-stream: 1fps ~ Real time frame rate
Video bit rate 1280 Kbps-7168 Mbps
Audio output 1-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbp
Dual-stream  Support
Stream type  Video, Video & Audio
Synchronous playback  16-ch
Playback resolution  1080P / 720P / WD1 / 4CIF / CIF / QCIF
Network
Remote connections 10
Network protocols TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA 2 SATA interface
Capacity Up to 4TB capacity for each disk
External interface
Network interface  10M / 100M /1000M
Serial interface  1; standard RS-485 serial interface, half-duplex
USB port 2 × USB2.0
Alarm in/out No
General
Power supply DC 12V
Consumption ≤ 15 W
Working temperature -0 °C ~ +55 °C(32°F - 131°F)
Working humidity 10% ~ 90%
Dimension

17.3 × 11.8 × 1.8"
440 × 300 × 45mm

Weight (without hard disk) ≤ 4.4 lb (2Kg)

LTS

  • $ 27915
  • Save $ 9059
