| Specifications |
| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Slow Shutter |
Support |
| Lens |
2.8 - 12 mm @ F1.4, Motorized lens |
| Lens Mount |
Φ14 |
| Day & Night |
IR cut filter with auto switch |
| DNR |
3D DNR |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan: 0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Compression Standard |
| Video Compression |
H.264 / MJPEG/H.264 Zip+ |
| H.264 Type |
Main Profile |
| Video Bit Rate |
32 Kbps ~ 16 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image |
| Max. Resolution |
2688×1520 |
| Frame Rate |
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)
50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) |
| Image Setting |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC |
Support, zone configurable |
| ROI Codec |
Support |
| Network |
| Network Storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100M Ethernet port |
| On-board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| Reset |
Yes |
| General |
Working Temperature
/Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C)
Humidity 95% or less (non-condensing) |
| Power Supply |
DC12V ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5.5W (Max. 7.5 W with IR cut filter on) |
| IR Range |
Approx. 100ft(30 meters) |
| Weather Proof Ratings |
IP66 |
| Impact Protection |
IEC60068-275Eh, 20J; EN50102, up to IK10 |
| Dimensions |
Φ 5.5" x 3.9" (Φ 140 x 99.9mm) |
| Weight |
2.20lbs (1000 g) |
|
