Analog Advanced Level 8 Channel DVR - Compact Case (no HDD)


  • 8 Channel Digital Video Recorder
  • Video Input: 8CH
  • Video Output: CVBS, SPOT, VGA/HDMI
  • Pentaplex Operation: Record, Playback, Backup, Live & Remote Acess
  • Realtime Record: 8CH D1
  • Recording Rate: 8CH WD1@15fps
  • Playback Channel: 8CH
  • Video Bit Rate: 768 Kbps ~ 2560 Kbps, or user defined (Max. 2560 Kbps)
  • Audio In/Out: 4CH/1CH, RCA
  • Alarm In/Out: 8/1
  • Dual Stream: Support; Master Stream, Sub-Stream: CIF
  • USB: 2 USB 2.0
  • Network: 10/100M
  • Storage: 1 SATA up to 4TB
  • PTZ: 1 RS485
  • Backup: USB, Network
Recorder Series V Series
Recorder Channel 8-Channel
Recorder Case Compact Case
Recorder Technology DVR
Featured Product No
Specifications
System Compression Format Standard H.264
OS Embedded Linux
Video  Input 8CH, BNC (1.0Vp-p, 75Ω)
Standard Output 1*VGA: 1920x1080,1280x1024, 800x600, 1* BNC+1 Spot out
Advanced Output 1*HDMI : 1080P: 1920×1080/60Hz
Audio Audio Input 4CH, RCA (2.0 Vp-p, 1 kΩ)
Audio Output 1CH  RCA (Linear, 1 kΩ)
Bidirectional Talk 1-CH, RCA (2.0 Vp-p, 1 kΩ) (using 1ch audio input)
Alarm Alarm in/out 8CH/1CH
Recording Recording Resolution 15fps@960H / 30 fps@D1
Recording Mode Schedule, Manual,  Motion, Sensor
Playback Max Playback Channel 8CH
Search Mode time, event, file
Backup USB Disk USB or SATA
Remote Application Dual Stream Support; master stream, sub-stream
Browser IE (windows XP/2000/Vista/7) , Safari(Mac OS), Chrome,Firefox
CMS YES
Mobile Phone Broview for iPad/iPad2/iPhone//Android
User Access 10users online with professional authority management
Storage HDD 1x SATA, up to 3TB
Network Ethernet 1, RJ45 10M / 100M Ethernet interface
Protocol TCP/IP,UDP,DHCP,DNS,PPPoE,DDNS,SMTP
Others Power Supply DC12V
Consumption ≤ 10 W (without hard disk or DVD-R/W)
Operating Temperature -10 ºC ~ 55 ºc
Humidity 10% ~ 90% humidity
Product Dimension 300mm ×270mm ×58mm
