| Specifications |
| Camera |
| Image Sensor: |
1/3" Progressive Scan CMOS |
| Min. Illumination: |
0.028 lux @F2.0, AGC ON, 0 lux with IR |
| Shutter time: |
1/25s ~ 1/100,000s |
| Lens: |
4mm @F2.0
1280 x 960: angle of view: 73.1°
4mm@F2.0
1280 x 960: angle of view: 73.1°
|
| Lens Mount: |
M12 |
| Day& Night: |
IR cut filter with auto switch |
| Digital noise reduction: |
3D DNR |
|
| Compression Standard |
| Video Compression: |
H.264 / MPEG4 / MJPEG |
| Bit Rate: |
32 Kbps ~ 16 Mbps |
|
| Image |
| Max. Image Resolution: |
1280x960 |
| Frame Rate: |
60Hz: 30fps (1280 × 960), 30fps (1280 × 720)
50Hz: 25fps (1280 x 960), 25fps (1280 x 720)
|
| Image Settings: |
Saturation, brightness, contrast adjustable through client software or web browser |
| BLC: |
Yes, zone configurable |
|
| Network |
| Network Storage: |
NAS (iSCSI optional) |
| Alarm Trigger: |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,
802.1x, Qos (SIP, SRTP, IPv6 optional) |
| Security: |
User authentication, watermark |
| System Compatibility: |
ONVIF, PSIA, CGI |
|
| Interface |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
|
| General |
| Operating Conditions: |
-13°F ~ 140°F(-25°C ~ 60°C ) humidity 95% or less (non-condensing) |
| Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: |
max. 7W |
| Weather Proof: |
IP66 |
| IR Range: |
Up to 100ft(30m) |
| Dimensions: |
Φ5.0“× 3.9”(Φ127.0 x 97.5 mm)
|
| Weight: |
1.5 lb(670g) |
|
|
